The 2026 Harley-Davidson® Street Glide® Limited is a fully equipped touring motorcycle designed around long-distance capability, advanced rider technology, integrated storage, and a large-displacement V-Twin powertrain. Built on the FLHXL platform, this model combines the Milwaukee-Eight® VVT 117 engine with a six-speed transmission, a steel chassis, adjustable suspension components, integrated navigation, and a comprehensive suite of rider safety systems. The motorcycle also incorporates a large infotainment display, LED lighting throughout, multiple connectivity features, and substantial luggage capacity. Its technical package emphasizes performance, control, comfort, rider information, and touring functionality.
Engine and Powertrain
The 2026 Harley-Davidson® Street Glide® Limited is powered by the Milwaukee-Eight® VVT 117 engine, a 117 cubic inch, or 1,923 cc, V-Twin designed to deliver substantial torque and consistent power across the operating range. The engine uses pushrod-operated overhead valves with hydraulic self-adjusting lifters and four valves per cylinder. This valvetrain configuration supports precise valve operation while reducing routine adjustment requirements. A bore of 4.075 inches and a stroke of 4.5 inches establish the engine's displacement characteristics. The engine also features a 10.3:1 compression ratio, which forms part of its overall combustion and performance design.
Electronic Sequential Port Fuel Injection manages fuel delivery and supports consistent engine operation. Air enters through a fiberglass washable air cleaner, providing a reusable intake filtration solution. Exhaust gases flow through a 2-1-2 dual exhaust system equipped with tapered mufflers. Engine lubrication is handled by a pressurized dry-sump system that separates oil storage from the crankcase and supports consistent oil circulation.
Output and Performance Characteristics
Performance specifications highlight the capability of the Milwaukee-Eight® VVT 117 engine. The engine produces a measured 131 ft-lb of torque at 3,250 rpm and develops 106 horsepower, or 79 kW, at 4,600 rpm. These figures demonstrate the engine's emphasis on strong torque production while maintaining substantial horsepower output.
Fuel economy is listed at 45 mpg, or 5.1 l/100 km, using estimated city and highway testing methods. The motorcycle carries six gallons of fuel, providing significant onboard capacity for touring use. A one-gallon reserve fuel capacity is associated with the fuel injection warning system. This fuel capacity works alongside the engine's efficiency characteristics to support extended riding intervals between refueling stops.
Transmission and Drivetrain Systems
The drivetrain of the 2026 Harley-Davidson® Street Glide® Limited is built around a 6-Speed Cruise Drive® transmission. This transmission works in conjunction with a mechanically actuated ten-plate wet clutch featuring Assist and Slip functionality. The clutch design supports smooth engagement and integrates directly with the motorcycle's drivetrain architecture. Power flows through a chain-driven primary drive system with a 34/46 ratio before being transferred to the rear wheel through a belt final drive with a 32/68 ratio.
Gear Ratios and Mechanical Configuration
The transmission utilizes six distinct overall gear ratios. First gear is listed at 9.593, followed by 6.65 in second gear and 4.938 in third gear. Fourth gear carries a ratio of 4.000, while fifth gear is rated at 3.407 and sixth gear at 2.875. These progressively spaced ratios define the motorcycle's mechanical gearing structure and determine how engine output is distributed across the operating range.
Fluid capacities further support drivetrain operation and maintenance requirements. Transmission capacity is listed at one quart, while the primary chain case holds 1.1 quarts. Engine oil capacity with filter is five quarts, and coolant capacity is specified at 0.82 quarts. These capacities define the motorcycle's service-related fluid requirements and support the operation of its mechanical systems.
Chassis Engineering and Dimensions
The chassis of the 2026 Harley-Davidson® Street Glide® Limited uses a mild steel tubular frame constructed around a two-piece stamped and welded backbone. Cast and forged junctions strengthen key connection points throughout the structure. The frame also incorporates twin down tubes, a bolt-on rear frame section, and forged fender supports. MIG welding is used throughout the assembly process, contributing to the motorcycle's structural configuration.
The swingarm follows a similarly robust design. It is manufactured from mild steel and utilizes a two-piece drawn and welded section with forged junctions and MIG-welded construction.
Dimensions and Rider Accommodation
The 2026 Harley-Davidson® Street Glide® Limited measures 103.3 inches in overall length, 40.7 inches in width, and 56.7 inches in height. A wheelbase of 64 inches contributes to the motorcycle's overall chassis proportions and touring-oriented layout. The motorcycle features a laden seat height of 27.5 inches and an unladen seat height of 29.1 inches. Static ground clearance is listed at 5.9 inches.
The 2026 Harley-Davidson® Street Glide® Limited weighs 855 pounds as shipped and 893 pounds in running order. Gross Vehicle Weight Rating is listed at 1,360 pounds. Gross axle weight ratings are 500 pounds for the front axle and 927 pounds for the rear axle.
Suspension, Wheels, and Handling Components
The suspension package combines a 49 mm Dual Bending Valve front fork with adjustable rear suspension components. This arrangement provides a balanced chassis configuration designed to support rider comfort and vehicle control. The front suspension offers 4.6 inches of travel, while the rear suspension travel measures 3 inches. The suspension package works directly with the frame geometry to influence handling and stability.
Rear Suspension Design
The rear suspension uses dual adjustable emulsion shocks. The left shock incorporates remote preload adjustment, while the right shock utilizes threaded preload adjustment. This configuration allows preload settings to be tailored through the provided adjustment mechanisms. The dual-shock design forms an important component of the motorcycle's touring-oriented chassis package. By combining adjustability with a dedicated suspension layout, the system supports varying rider and cargo configurations within the motorcycle's rated capacities.
Steering Geometry and Wheels
The motorcycle's steering geometry includes a 26-degree rake and a 29.25-degree fork angle. The trail measures 6.7 inches, defining another key element of the steering specification. Lean angle capability is listed at 31 degrees on both the right and left sides. These measurements provide insight into the motorcycle's handling geometry and chassis layout.
Cast aluminum wheels are fitted at both ends of the motorcycle. The front wheel measures 19 inches in diameter and 3.5 inches in width, while the rear wheel measures 18 inches in diameter and 5 inches in width. Tire fitment consists of a Dunlop® Harley-Davidson® Series D408F front tire in size 130/60B19 M/C 61H and a Dunlop® Harley-Davidson® Series D407T rear tire in size 180/55B18 M/C 80H. Together, these wheel and tire specifications form the motorcycle's complete rolling chassis package.
Braking Systems and Rider Safety Technologies
The braking system of the 2026 Harley-Davidson® Street Glide® Limited incorporates dual front brake rotors and a single rear rotor. The front braking assembly uses dual floating rotors with a diameter of 12.6 inches and a thickness of 0.18 inches. The rear braking assembly utilizes a fixed rotor measuring 11.8 inches in diameter and 0.28 inches in thickness. Braking force is managed by 32 mm four-piston fixed dual axially mounted front calipers and a single axially mounted rear caliper. These components form the motorcycle's primary braking hardware.
Standard Rider Safety Enhancements
The motorcycle includes Anti-lock Brake System, Electronic Linked Braking, Traction Control System, Drag-torque Slip Control System, Vehicle Hold Control, and Tire Pressure Monitoring System. These systems provide electronic assistance for braking performance, traction management, hill-hold functionality, and tire pressure monitoring. Their integration expands the motorcycle's safety technology package beyond mechanical braking components. Each system contributes a specific operational function designed to support rider control and vehicle management.
Cornering Rider Safety Enhancements
The 2026 Harley-Davidson® Street Glide® Limited also incorporates cornering-focused rider safety technologies. Included systems consist of Cornering Enhanced Anti-lock Brake System, Cornering Enhanced Electronic Linked Braking, Cornering Enhanced Traction Control System, and Cornering Drag-Torque Slip Control System. These systems build upon the standard rider safety package by incorporating cornering-sensitive functionality. The motorcycle, therefore, combines multiple layers of electronic assistance across braking and traction-related operations. Together, these technologies represent a comprehensive collection of rider support systems integrated into the vehicle.
Electrical System and Lighting Equipment
The electrical system is built around a sealed, maintenance-free 12-volt battery rated at 28 amp-hours and 405 cold cranking amps. Charging duties are handled by a three-phase 58-amp system capable of producing up to 754 watts at 13 volts. Engine starting is performed through a 1.6 kW electric system with solenoid shift starter motor engagement. These components establish the foundation of the motorcycle's electrical architecture. They support the operation of onboard electronics, infotainment functions, lighting systems, and rider-assistance technologies.
LED Lighting Configuration
LED lighting is used throughout the motorcycle. The headlamp utilizes LED technology, as do the tail and stop lamps. Front signal lights and rear turn signals also employ LED lighting. Additional illumination is provided by LED fog lamps integrated into the lower fairings. This consistent lighting specification creates a unified lighting package across the motorcycle's primary and auxiliary systems.
Infotainment, Navigation, and Connectivity
The 2026 Harley-Davidson® Street Glide® Limited incorporates the Skyline™ OS infotainment platform. The system operates through a 12.3-inch full-color TFT display that also houses the motorcycle's digital gauges. Vehicle information functions include displays for air temperature, oil pressure, and EITMS information. This integration places operational data and infotainment functions within a single display environment.
Audio and Media Functions
The audio system features four speakers powered by 50 watts per channel. Two 6.5-inch speakers are mounted within the fairing, while two additional 6.5-inch speakers are located in the Tour-Pak®. AM and FM radio functionality are included as standard equipment. USB-connected SD cards, flash drives, and MP3 playback are supported through the system. These features provide multiple options for media access and audio playback.
Connectivity and Navigation Features
Bluetooth® functionality supports phone, media player, and headset connectivity. Hands-free mobile phone capability is included as standard equipment. Apple CarPlay® compatibility is available through either wired or wireless connection methods. USB-C connectivity supports compatible devices using appropriate adapters connected through the inner fairing storage area. The motorcycle also includes an embedded navigation system with traffic and weather information available through a Wi-Fi hotspot connection.
Comfort, Storage, and Touring Functionality
The 2026 Harley-Davidson® Street Glide® Limited incorporates several features that support long-distance touring operation. Integrated electrical access includes a 15-watt USB-C power accessory port located in the media storage box, along with an additional electric power accessory port in the Tour-Pak®. These connections provide convenient power access for compatible devices carried during travel. The motorcycle also supports rider and passenger intercom functionality when compatible headsets are used. VOX capability is available for Harley-Davidson® headsets.
Cargo Capacity and Utility Features
Storage capacity is an important component of the 2026 Harley-Davidson® Street Glide® Limited's touring configuration. The motorcycle provides 5.05 cubic feet of luggage volume for carrying travel-related cargo and personal items. This capacity complements the integrated infotainment, navigation, and connectivity systems by supporting extended-distance riding requirements.
