The 2026 Harley-Davidson® Road Glide® 3 is engineered as a three-wheel touring platform that combines a large-displacement V-twin engine, a reinforced chassis, and integrated electronic systems. The model is designed to provide stable handling through its trike configuration while maintaining consistent power delivery and rider control. Its structure, drivetrain, and onboard technology systems are configured to support extended travel, controlled maneuverability, and system integration across performance, braking, and infotainment functions. The fixed fairing, wide stance, and low seat height contribute to a design that prioritizes predictable operation and rider accessibility.
Engine Specifications and Output Characteristics
The 2026 Harley-Davidson® Road Glide® 3 is powered by a Milwaukee-Eight® VVT 117 engine with a displacement of 117 cubic inches or 1,923 cubic centimeters. This engine uses a pushrod-operated overhead valve configuration with hydraulic, self-adjusting lifters and four valves per cylinder. The design supports consistent valve operation and reduces the need for periodic adjustments. The bore measures 4.075 inches and the stroke measures 4.5 inches, creating a long-stroke configuration that supports torque production at lower engine speeds.
The engine produces 129 foot-pounds of torque at 3,250 revolutions per minute and delivers 105 horsepower at 4,600 revolutions per minute. A compression ratio of 10.3 to 1 supports efficient combustion. The fuel system uses Electronic Sequential Port Fuel Injection, which meters fuel delivery based on operating conditions. The lubrication system is pressurized and dry-sump, ensuring stable oil distribution under varying load conditions. Air intake is managed through a washable paper air cleaner, and exhaust gases are routed through a 2-1-2 dual exhaust configuration.
Variable Valve Timing is integrated into the engine design to adjust valve operation based on engine speed and load. This system improves efficiency across a range of operating conditions and contributes to smoother throttle response. The engine is configured to run on premium fuel with a recommended octane rating of 91 or higher.
Transmission and Drivetrain Architecture
The drivetrain is configured to deliver power efficiently while maintaining durability. A chain-driven primary system connects the engine to the transmission with a 34 to 46 ratio. Final power transfer is handled through a belt drive with a 30 to 70 ratio, which reduces maintenance requirements and operating noise compared to chain-driven alternatives.
The transmission is a 6-speed Cruise Drive® system that includes an integrated reverse function. The reverse system is electrically actuated through handlebar-mounted controls, allowing controlled backward movement of the vehicle.
The clutch is a mechanically actuated, ten-plate wet assist and slip design. This configuration reduces clutch lever effort and provides smoother engagement during gear changes. Gear ratios are spaced to support both low-speed maneuvering and sustained highway operation. The first gear ratio is 10.534, while the sixth gear ratio is 3.0, allowing reduced engine speed at cruising velocities.
Chassis Structure and Dimensional Configuration
The chassis is constructed using a mild steel frame with a square-section backbone and twin downtubes. This structure provides rigidity and supports the additional load associated with a three-wheel configuration. The swingarm is made from permanent mold cast aluminum, which reduces weight while maintaining structural strength.
The overall length of the vehicle measures 103 inches, and the wheelbase is 67.7 inches. The width is 57.5 inches, reflecting the trike layout. The seat height in a laden condition is 26.5 inches, while the unladen seat height measures 27.9 inches. Ground clearance is 5.5 inches, which allows adequate clearance for standard road conditions.
The rake angle is set at 26 degrees, and the trail measures 3.8 inches. These geometry values contribute to stable steering and predictable handling. The total running weight is 1,184 pounds, and the gross vehicle weight rating is 1,700 pounds. The front axle rating is 511 pounds, and the rear axle rating is 1,189 pounds, reflecting the load distribution across the trike platform.
Suspension System and Ride Control
The front suspension uses a 49 millimeter dual bending valve fork with 4.6 inches of travel. This fork design improves damping control by separating compression and rebound forces, resulting in more consistent front-end behavior. The rear suspension consists of hand-adjustable emulsion shocks with 3.5 inches of travel. These shocks allow preload adjustment based on rider weight and cargo load.
Suspension tuning is configured to balance ride comfort and handling stability. The front and rear travel measurements support absorption of road irregularities while maintaining consistent tire contact. The geometry and suspension work together to provide controlled steering input and reduced oscillation during extended riding.
Wheels, Tires, and Braking Components
The 2026 Harley-Davidson® Road Glide® 3 is equipped with cast aluminum wheels featuring a gloss black and machined finish. The front wheel measures 19 inches in diameter and 3.5 inches in width. The rear wheels measure 18 inches in diameter and 7 inches in width. Tire specifications include a front tire sized at MT 130/60B19 M/C 61H and rear tires sized at P215/45R18 83T.
The braking system includes dual floating rotors at the front with a diameter of 11.8 inches and a thickness of 0.197 inches. The front calipers are 32 millimeter four-piston fixed units. The rear braking system uses a fixed rotor with a diameter of 11.8 inches and a thickness of 0.276 inches, combined with a floating 36 millimeter piston caliper that integrates a parking brake function.
An Anti-lock Braking System is included as standard equipment. This system monitors wheel speed and modulates brake pressure to prevent wheel lock during braking. The braking configuration is designed to provide consistent stopping performance under varying load and road conditions.
Electrical System and Lighting Configuration
The electrical system is based on a sealed, maintenance-free 12-volt battery with a capacity of 28 amp-hours and a rating of 405 cold cranking amps. The charging system is a three-phase unit capable of producing 600 watts at 13 volts at 2,000 revolutions per minute and up to 625 watts maximum output.
The starting system uses a 1.6 kilowatt electric starter motor with solenoid engagement. Lighting components include an LED headlamp, LED tail and stop lights, and LED front and rear turn signals. LED lighting improves visibility and reduces power consumption compared to traditional lighting systems.
A USB-C power outlet rated at 15 watts is located in the media storage compartment, allowing device charging during operation. The electrical system is designed to support onboard electronics, lighting, and accessory usage without exceeding system capacity.
Infotainment System and Connectivity Features
The infotainment system operates on Skyline™ OS and is displayed through a 12.3 inch full-color TFT screen. This display integrates vehicle data, navigation, and media controls into a single interface. The system includes embedded navigation functionality with traffic and weather data provided through a Wi-Fi hotspot connection.
Audio output is delivered through two speakers, each measuring 5.25 inches, with an output of 50 watts per channel. The system supports AM and FM radio, as well as media playback through USB-connected devices. Bluetooth® connectivity allows pairing with mobile phones for hands-free communication and media streaming.
Apple CarPlay® compatibility is included and supports both wired and wireless connections. The system also includes a vehicle information display that provides data such as air temperature, oil pressure, and engine idle temperature management system status. USB-C connectivity supports media transfer protocol and smartphone integration through adapters.
Rider Safety and Control Systems
The 2026 Harley-Davidson® Road Glide® 3 includes a range of electronic rider safety systems designed to improve stability and control. The standard systems include Anti-lock Braking System, Electronic Linked Braking, Traction Control System, and Drag-torque Slip Control System. These systems operate together to manage braking force, traction, and engine braking under varying conditions.
Cornering-enhanced versions of these systems are also included. Cornering Anti-lock Braking System adjusts braking force based on lean angle. Cornering Electronic Linked Braking distributes braking force between front and rear wheels during turns. Cornering Traction Control monitors wheel slip while cornering, and Cornering Drag-torque Slip Control manages rear wheel behavior during downshifting.
A Tire Pressure Monitoring System is included and provides continuous monitoring of tire pressure levels. This system alerts the rider to deviations from recommended pressure values, supporting consistent tire performance and safety.
Fuel Capacity and Efficiency Metrics
The fuel tank has a capacity of 6 gallons, with a reserve capacity of approximately 1 gallon. The estimated fuel economy is 39 miles per gallon under combined city and highway conditions. These values support extended travel distances between refueling stops.
Fluid capacities include 5 quarts of engine oil, 1.1 quarts for the transmission, and 0.82 quarts of coolant. These capacities are configured to maintain stable operation under sustained riding conditions and varying environmental factors.
Storage Capacity and Practical Integration
The 2026 Harley-Davidson® Road Glide® 3 includes a luggage capacity of 2 cubic feet, allowing storage of essential touring equipment. Storage compartments are integrated into the fairing and rear section, providing accessible space for personal items and electronic devices. The placement of storage components supports weight distribution and ease of access during travel.
