The 2026 Harley-Davidson® CVO™ Street Glide® 3 Limited is engineered as a full-size touring motorcycle that combines large-displacement power, integrated electronics, and structural design focused on stability and long-distance function. The model uses a high-capacity Milwaukee-Eight® VVT 121 engine, a six-speed Cruise Drive® transmission with reverse, and a chassis designed to support both rider control and loaded touring conditions. Its technical specification reflects a focus on measurable performance, balanced geometry, and rider-assistance systems that support control during braking, acceleration, and cornering.
Dimensions confirm the scale of the motorcycle. Overall length measures 105.7 inches, width is 57.3 inches, and height is 56.5 inches. Seat height in laden condition measures 27.3 inches, while unladen seat height is 28.9 inches. Ground clearance is listed at 5.1 inches. Combined with a 67.7-inch wheelbase and a 26-degree rake, these measurements contribute to predictable straight-line behavior and controlled steering response during highway use. Weight in running order is listed at 1,283 pounds, supporting the touring classification of the platform while maintaining controlled geometry through chassis design and suspension setup.
Engine Configuration and Mechanical Output
The engine specification defines the technical identity of this model. The Milwaukee-Eight® VVT 121 engine uses a displacement of 121 cubic inches, equivalent to 1,977 cc. The engine features a bore measurement of 4.075 inches and a stroke of 4.625 inches, showing a long-stroke layout that prioritizes low- and mid-range torque delivery. Compression ratio is rated at 11.4:1, contributing to combustion efficiency and responsive throttle input.
The valvetrain uses pushrod-operated overhead valves with hydraulic self-adjusting lifters and four valves per cylinder. This design reduces maintenance requirements associated with valve adjustment while maintaining airflow capacity suitable for a large displacement touring engine. Fuel delivery is controlled through Electronic Sequential Port Fuel Injection, supporting consistent fueling during varying operating temperatures and riding conditions. The air intake system uses a synthetic felt washable air cleaner, while exhaust routing uses a 2-1-2 dual exhaust configuration designed for balanced flow and stable back pressure.
Performance ratings list peak torque at 138 foot-pounds at 3,750 rpm and power output of 114 horsepower at 4,500 rpm. These values reflect a torque-focused tuning approach that supports acceleration under load and smooth highway passing response. The lubrication system is pressurized and dry-sump, aiding long-distance durability and consistent oil circulation during extended operation.
Transmission, Gear Ratios, and Drivetrain Mechanics
Power transfer uses a six-speed Cruise Drive® transmission equipped with reverse. This configuration supports controlled low-speed movement during parking or tight maneuvering situations. The transmission ratios show a progressive spread designed to balance acceleration and touring comfort. First gear ratio is 10.534 overall, followed by 7.302 in second, 5.423 in third, 4.392 in fourth, 3.742 in fifth, and 3.0 in sixth gear. This progression reduces engine rpm during highway cruising and contributes to smoother long-distance operation.
Primary drive uses a chain system with a 34/46 ratio, while the final drive uses a belt with a 30/70 ratio. The belt final drive reduces routine maintenance compared to chain systems and contributes to smoother power transfer. Clutch operation is handled by a mechanically actuated ten-plate wet clutch featuring assist-and-slip functionality. This system reduces lever effort and supports smoother downshifts by limiting rear-wheel instability during deceleration.
Transmission calibration and drivetrain layout work together to maintain predictable engagement across speed ranges. These technical choices support a consistent riding experience under touring loads and during urban operation.
Frame Construction, Suspension, and Handling Structure
The chassis uses a mild steel square-section backbone frame with twin downtubes. This configuration provides structural rigidity while maintaining load support for passenger and luggage capacity. The swingarm is manufactured using permanent mold cast aluminum, helping reduce unsprung mass and improve suspension response.
Front suspension uses a 49 mm dual bending valve front fork. This design improves damping control across varying road surfaces and maintains steering stability during braking. Rear suspension uses a hand-adjustable emulsion shock system, allowing changes in setup based on rider weight or cargo requirements. Suspension travel is measured at 4.6 inches in the front and 3.46 inches at the rear, offering a balance between comfort and controlled chassis movement.
Steering geometry includes a fork angle of 32 degrees and a trail measurement of 3.8 inches. These specifications help manage low-speed stability while maintaining predictability at highway speeds. Combined with the long wheelbase, the chassis is tuned for directional stability rather than aggressive corner entry, which aligns with the motorcycle’s touring intent.
Wheels, Tires, and Braking Hardware
Wheel specification includes dual-grain chrome 14-spoke wheels. The front wheel diameter measures 19 inches with a width of 3.5 inches, while the rear wheel measures 18 inches in diameter and 7 inches in width. Tires are Dunlop® Harley-Davidson® Series units with bias blackwall front construction and radial rear construction. The front tire specification is 130/60B19, and the rear tire specification is P215/45R18.
Braking hardware is designed for consistent stopping force under high weight loads. Front braking uses dual floating rotors paired with fixed 32 mm four-piston calipers. Rear braking uses a fixed rotor and a floating 36 mm piston integrated park brake. Rotor diameter measures 11.8 inches both front and rear. Front rotor thickness is 0.197 inches, and rear rotor thickness measures 0.276 inches. Dual front brakes provide balanced stopping power suitable for touring operation.
The system includes Anti-Lock Braking System functionality as standard. Electronic Linked Braking distributes braking force between front and rear wheels to improve stability during deceleration. These electronic systems function alongside the mechanical components to maintain predictable stopping behavior across different road conditions.
Rider Safety Systems and Electronic Stability Functions
Rider safety enhancements include multiple control systems designed to support traction and stability. The Traction Control System monitors wheel behavior to reduce unwanted slip during acceleration. The Drag-Torque Slip Control System assists in managing engine braking effects during aggressive downshifts. Vehicle Hold Control is included to help maintain position on inclines during stopped conditions. The Tire Pressure Monitoring System provides continuous monitoring of tire inflation status to support safe operation.
Cornering-enhanced systems add additional sensor-based refinement. The Cornering Enhanced Anti-Lock Braking System adjusts braking intervention based on lean angle input. Cornering Enhanced Electronic Linked Braking and Cornering Enhanced Traction Control maintain balanced chassis response during turns. Cornering Drag-torque Slip Control further regulates rear wheel behavior when decelerating while leaned over. These systems operate together to support rider control through varying riding inputs and road conditions.
Electrical System and Lighting Architecture
The electrical system uses a sealed, maintenance-free 12-volt battery rated at 28 amp-hours and 405 cold cranking amps. Charging capability is supported by a three-phase 48-amp system producing up to 625 watts maximum output. This power capacity supports lighting, infotainment, navigation, and accessory charging without exceeding system limits.
Starting operation uses a 1.6 kW electric starter with solenoid shift motor engagement. Lighting systems use LED technology across the motorcycle, including the headlamp, tail and stop lamps, front signal lights, rear turn signals, and integrated fog lamps located in the lower fairings. LED lighting improves visibility while reducing electrical load and extending service life.
A USB-C power outlet rated at 15 watts is located in the media storage compartment for device charging. Digital gauges are integrated into the central display, consolidating vehicle information into a unified visual interface.
Infotainment System and Connectivity Integration
The infotainment platform of the 2026 Harley-Davidson® CVO™ Street Glide® 3 Limited uses Skyline™ OS and features a 12.3-inch full-color TFT display. The screen integrates digital instrumentation, navigation functions, media playback, and system information. Six speakers are included, consisting of two fairing-mounted speakers, two Tour-Pak® speakers, and two lower fairing speakers. Each speaker measures 6.5 inches. Audio amplification includes multiple channel outputs rated up to 150 watts in selected channels.
Connectivity features include Bluetooth® support for phone and media integration, wireless or wired Apple CarPlay® compatibility, and headset support through Bluetooth®. The system supports USB connectivity for media playback and external device access. Navigation functionality is embedded and supported through onboard systems. The vehicle information screen displays operational data such as air temperature, oil pressure, and engine management information.
Hands-free mobile phone capability and rider-passenger intercom functionality are included as standard features. These integrations are designed to reduce external device clutter while maintaining rider access to communication and navigation tools.
Fuel Capacity, Storage Capacity, and Touring Function
Fuel capacity is listed at six gallons, with an additional one-gallon reserve warning threshold. Oil capacity with filter measures five quarts. Transmission capacity is 1.22 quarts, and primary chain case capacity measures 1.1 quarts. Coolant capacity is rated at 0.82 quart. These capacities align with the motorcycle’s long-distance touring design, allowing extended operation before servicing requirements.
Luggage capacity is rated at 7.1 cubic feet, supporting transportation of riding gear and travel equipment. Combined with the platform’s structural frame design and high gross vehicle weight rating, this capacity supports touring use with passenger and cargo loads. Electric reverse functionality adds convenience during parking maneuvers due to the overall size and weight of the motorcycle.
Estimated fuel economy is listed at 39 miles per gallon under combined city and highway testing standards, supporting extended travel distance per fuel stop.
